AM4113T5

The Dino-Lite Pro AM4113T5 provides all the features of the standard AM413T but uses high magnification 500x optics to allow even more detailed inspection. Primarily designed for contact inspection this model offers the ideal solution where high magnification inspection is required.

Additional Info

  • Resolution: 1280x1024pixels(1,3MP)
  • Magnification: 500x fixed focus magnification
  • Working Distance: Contact
  • Interface: USB 2.0
  • Nr. of LED's: 8
  • LED on/off switchable: Yes
  • LED color: White
  • Material: Composite
  • Exchangeable caps: No
  • Microtouch: Yes
  • Scroll lock: Yes
  • Output: Picture, Video, Time-lapsed video
  • Video Frame Rate: Up to 30 frames-per-second, 15fps at 1.3M
  • Measurement: Yes
  • Calibration: Yes
  • Filter/Diffuser: None
  • Compatibility: Windows XP, Windows XP / Vista, Windows 7 / 8 / 10, MacOS [see compatibility chart]
  • Software: DinoCapture for Windows, DinoXcope for MacOS
  • JPEG Codec: None
  • Special: Latest version of the AM413T5, now with scroll lock function.
  • Field of View:
    M WD FOV (x) FOV (y)
    515 0.1 0.8 0.6

    M = magnification rate, WD = working distance, FOV = field of view, Unit = mm
